The new mechanical Record 12x2 Speed derailleur: speed, dexterity, precision and effectiveness.
The Campy Tech Lab designers focused on functionality, performance and compatibility when redesigning the new front derailleur. The new Record™ mechanical 12x2 Speed derailleur reveals various technical innovations; starting with the leverage system, which is designed to speed up shifting. Less effort is required for shifting thanks to the split front link rod, which avoids contact with the travel limit screw, and the shape of the inner cage plate, designed to match the new 12 speed chain’s characteristics.
The micro-adjustments to the front derailleur position (which can be activated by the controls) make it possible to avoid any chain contact, even in cases of maximum crossing. The plate positioned on the aluminium outer cage prevents the chain from escaping when upshifting and increases speed in the downshift phase, as well as creating a quieter transmission.
As far as compatibility is concerned, the new Record™ 12x2 Speed front derailleur allows tyres up to 32mm thanks to the new upper connecting rod and the double fixing of the cablex.
81g
Forged aluminium construction and steel screws.
Upper connecting rod not connected to the external one
More effective, precise movement, without contacting the limit stop.
Cage plate designed to improve occurrences of maximal chain crossing
The derailleur avoids contact and friction with the transmission.
Ideal for wider tyres
Tyres of up to a 32 mm cross-section can be fitted without risking contact with the front derailleur.
Optimized inner cage plate design
Accurately accompanies the chain on the largest chainring
Cable fixed in double position
Maximum compatibility with frames.
